Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of german standard rails in China, also supports customized service with low price. Please feel free to buy cheap german standard rails made in China here from our factory.
German standard rails specifications
Specifications: A45, A55, A65, A75, A100, A120, A150,
Standard: DIN536,
Material: ASSZ-1/75V/u71Mm/1100/900A/700,
Length: 8-25m.
Technical parameters of German standard rails
|
Rail Type |
Height (mm) |
Head width (mm) |
Base width |
Web thickness (mm) |
Head Depth |
Base Depth (mm) |
Nominal Weight (kg/m) |
Cross Section area |
|
A45 |
55 |
45 |
125 |
24 |
20 |
8 |
22.1 |
28.2 |
|
A55 |
65 |
55 |
150 |
31 |
25 |
9 |
31.8 |
40.5 |
|
A65 |
75 |
65 |
175 |
38 |
30 |
10 |
43.1 |
54.9 |
|
A75 |
85 |
75 |
200 |
45 |
35 |
11 |
56.2 |
71.6 |
|
A100 |
95 |
100 |
200 |
60 |
40 |
12 |
74.3 |
94.7 |
|
A120 |
105 |
120 |
220 |
72 |
47 |
14 |
100 |
127.4 |
|
A150 |
150 |
150 |
220 |
80 |
50 |
14 |
150.3 |
191.4 |
