Crane Rail Clips
GNEE RAIL is a specialized manufacturer and global supplier of crane rail clips, offering secure and reliable fastening solutions for crane rail systems used in ports, steel plants, shipyards, warehouses, and heavy industrial facilities. With years of experience in railway and crane rail fastening systems, GNEE RAIL has established itself as a trusted partner for demanding industrial applications.
GNEE RAIL crane rail clips are designed to provide stable rail fixation, effective vibration control, and long-term resistance to dynamic loads generated by overhead cranes and gantry cranes. Manufactured using high-strength alloy steel or spring steel, the clips undergo precision forming, controlled heat treatment, and surface finishing processes to ensure excellent elasticity, fatigue resistance, and corrosion protection. All production is carried out under an ISO 9001 certified quality management system, with strict inspection of mechanical properties and dimensional accuracy.
GNEE RAIL offers a wide range of crane rail clip types compatible with DIN 536 crane rails, QU rails, and custom crane rail sections, and supports various installation conditions including embedded rails, concrete foundations, and steel structures. Customized clip designs, coatings, and complete fastening assemblies can be provided according to project requirements and international standards.
-
![Crane Rail System Fixing Clips]()
Crane Rail System Fixing ClipsCrane rail fastening system is used to fix the crane railway, connect the pieces of crane rails into a continuous railway line. The crane rail fastening system is made up of some parts including...read more -
![WJK QU80 Rail Clip]()
WJK QU80 Rail ClipThe Rail clip is a rail-fixing device. Its function is to press and fix the rail.read more -
![TG43 Rail Clip]()
TG43 Rail ClipThe Rail clip is a rail-fixing device. Its function is to press and fix the rail.read more -
![1220 Crane Rail Clip]()
1220 Crane Rail ClipThe Rail clip is a rail-fixing device. Its function is to press and fix the rail.read more -
![3124 Crane Rail Clip]()
3124 Crane Rail ClipRail Clips are the key fasteners of the rail system. How choose the right Rail clips is very important. According to the track installation foundation and usage environment, as well as the track...read more
Why choose us
One-Stop Service
We offer a full range of services to meet all your rail fastening system needs, from design and manufacturing to installation and maintenance.
Commitment to Quality
Quality is our top priority, and we adhere to stringent quality control measures throughout the production process to deliver products that meet or exceed industry standards.
Market-Focused Solutions
We stay informed about market trends and developments to provide innovative solutions that address current challenges and anticipate future needs.
Professional Technical Team
Our team of experts brings years of experience and specialized knowledge to ensure that your rail fastening system is designed to meet the highest standards of quality and performance.
Customer-Centric Approach
We prioritize customer satisfaction and strive to understand and fulfill our clients' unique requirements. Our customer-centric approach ensures that your needs are met promptly and effectively.
Sales Market
GNEE RAIL maintains an established global supply footprint, delivering engineered track components and fastening assemblies to key transportation networks, industrial zones, and maritime ports across multiple continents.
Crane Rail Clips
A crane rail clip, also known as a welded crane rail clip, welded rail fixing device, steel beam railing device, or welded pressure plate, is used to press and fix the rail in place. Typically, it is welded onto I-beams and sometimes onto steel plates that are pre-buried in concrete.
Crane rail clips can be classified into WJK, SWJK, and HWJK series, including types like TG38, TG43, TG50, TG60, QU70, QU80, QU100, and QU120. These clips consist of several components, including the base, upper cover, wearing shaft, and flat washer.
Welded rail clips can be fixed directly to the steel surface supporting the rail. This design simplifies construction and maintenance access, making it easier to service cranes while in operation.
Some types of crane rail clips have a compact design, allowing them to be used with cranes equipped with guide rollers. All clips are adjustable, but the adjustments are made within the limits defined by structural engineering design practices. It is typically required to ensure that the centerline of the rail aligns with the thickness of the crane runway beam web.
|
