Railroad Fish Plates
A railway fish plate is a metal joint bar that functions by connecting the ends of two rail sections together using rail bolts.
GNEE RAIL has over 18 years of experience in manufacturing rail fish plates. We have the capability to produce all types of fish plates suitable for various rail sections, such as UIC 60, UIC 54, U33, BS 80A, BS 90A, IRS 52 KG, IRS 90 Lbs, 115 RE, 136 RE, TJ 45, TJ 37, RN 45, and more.
We supply fish plates in accordance with international standards such as BS, ASTM, DIN, and others. Our factory is equipped for rolling, forging, machining, drilling, and punching, allowing us to customize rail fish plates based on customer-supplied drawings.
|
Rail Joint For Light Rail |
|||||
|
Rail Size(kg/m) |
Main dimension(mm) |
Theoretical Weight(kg/piece) |
|||
|
Legth |
Width |
Holt Diameter |
Holt Count |
||
|
9 |
385 |
43.13 |
14 |
4 |
0.81 |
|
12 |
409 |
46.5 |
14 |
4 |
1.39 |
|
15 |
409 |
53.54 |
18 |
4 |
2.2 |
|
22 |
510 |
61.73 |
22 |
4 |
3.8 |
|
30 |
561 |
71.48 |
22 |
4 |
5.54 |
|
Rail Joint For Heavy Rail |
|||||
|
Rail Size(kg/m) |
Main dimension(mm) |
Theoretical Weight(kg/piece) |
|||
|
Legth |
Width |
Holt Diameter |
Holt Count |
||
|
38,43 |
790 |
94.03 |
40 |
6 |
15.57 |
|
50 |
820 |
104.22 |
46 |
6 |
18.72 |
|
Standard |
Type |
Length/Diameter |
Weight/Material |
|
AREMA |
115RE |
4 holes-24″ |
17.04kg |
|
115RE |
6 holes-36″ |
25.56kg |
|
|
132RE-136RE |
4 holes-24″ |
17.75kg |
|
|
132RE-136RE |
6 holes-36″ |
26.63kg |
Other sizes of rail joint according to your requirements. Such As Jis Standard Rail Joint, UIC Standard Rail Joint, Din Standard Rail Joint, etc.
Distinguish with material: Nodular cast iron, Q235, forge.
Application: A fishplate is a fastener used to connect the rail to the rail.
Types of Fish Plates
Normal Fish Plate
We offer 4-hole and 6-hole fish plates suitable for various rail types, including 60 kg, 54 kg UIC, 52 kg UIC, 90A, 90R, 80A, 80'O', 88'O', 75R, 60R, 115 RE, 132 RE, and 50R rails.
Joggled Fish Plate
Joggled fish plates are designed for temporary repair of cracked welded rail joints. They include a clamp assembly and are compatible with various rail sections.
Compromise Fish Plate
Compromise fish plates are specially designed to join two different rail sections. We manufacture them based on customer requirements for diverse applications.
The railway fish plate installation procedure can be summarized in four steps:
Install Spring Washers And Flat Washers
Before inserting the fish bolts. The openings of the washers should face downward.
Turn Off The Power
Before starting the installation of the railway fish plate.
Install Two Rail Bolts
At each connection joint.
Apply Oil
To the railway fish plates, rail tracks, and fish bolts before final installation.
We focus on manufacturing high-quality track fasteners that meet the required specifications. We have a strict quality control process in place to ensure that our fish plates are of the highest quality.
We offer a wide range of track fasteners to meet the needs of different customers. We have standard fish plates, joggled, special and combination type. We also offer custom-made fish plates to meet the specific requirements of our customers.
