Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of gb steel rail 50kg 60kg 75kg in China, also supports customized service with low price. Please feel free to buy cheap gb steel rail 50kg 60kg 75kg made in China here from our factory.
Product Introduction
50kg/m Rail
Dimensions: Rail head width 70mm
Rail height 152mm
Rail bottom width 132mm
Rail waist thickness 15.5mm
Bolt hole diameter 31mm
Weight: Theoretical weight per meter is about 51.51kg.
Material: Common materials include U71Mn, etc.
60kg/m Rail
Dimensions: Rail head width 73mm
Rail height 176mm
Rail bottom width 150mm
Rail waist thickness 16.5mm
Weight: Theoretical weight per meter is about 60.64kg.
Material: Generally U71Mn, U75V, etc.
Application: It is a common rail type for main railway lines, suitable for mixed passenger and freight lines and high-speed railways that have high requirements for track bearing capacity and stability.
75kg/m rail
Dimensions: The rail head, rail waist and rail bottom are wider and thicker than those of 50kg/m and 60kg/m rails to meet heavy load requirements.
Weight: 75kg per meter.
Material: Such as U71Mn, U75V, etc.
Application: Mainly used in heavy-duty railways and particularly busy section railways, it can withstand larger train axle weights and transport volumes, and meet the needs of high-intensity transportation.
Product Application
Product Packaging & Delivery
Use steel belts or steel wires to bundle heavy rails to prevent damage during transportation. Use end protectors to protect the rail heads that are susceptible to wear. It can also be packaged and transported according to customer needs.
GNEE RAIL heavy rail products are exported to many countries and regions around the world. It has a wide range of customer groups in the international market, with more than 160 cooperative countries, and has established long-term cooperative relations with railway construction companies and rail transit operators in various countries.
GNEE always adheres to the "customer first" business philosophy, takes customer needs as the guide, and provides customers with high-quality products and services. We focus on establishing long-term and stable cooperative relations with customers, and win the trust and support of customers by continuously improving customer satisfaction.
