Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of 30-lb asce rail in China, also supports customized service with low price. Please feel free to buy cheap 30-lb asce rail made in China here from our factory.
30-lb ASCE Rail
The 30-lb ASCE Rail is designed to meet the specifications of the American Society of Civil Engineers (ASCE), making it suitable for use in the United States and other regions following ASCE railway standards. This rail weighs 30 pounds per yard, which is approximately 14.88 kilograms per meter. GNEE Rail is a reputable supplier of American standard rails, offering 12-lb ASCE Rail, along with ASCE 25, 30, 40, 60, 75, 85, 90RA, 115RE, 136RE, and 175LBS. We also manufacture various railway fasteners such as rail joint bars, railroad spikes, and track bolts, with the ability to customize products as needed. Contact us for further information.
30-lb ASCE Rail specification
Rail Type: 30 as
Section number: 3040
Nominal Weight: 25 lbs/yd
Standard Length: 30' (20' and 40' also available)
Standard Drilling: 2" x 4" with 3/4" diameter hole
Splice bar length: 16-1/8"
Splice bar weight: 6 lbs/pr with hardware: 8 lbs/pr
Track Bolts: 5/8" x 2-1/2"
30-lb ASCE Rail dimension
| Product Name | American Standard Rail | ||||||
| Standard | ASTM A1/AREMA | ||||||
| Model | DIMENSION | Weight | Material | Length | |||
| A(mm) | B(mm) | C(mm) | t(mm) | (KG/M) | (m/PC) | ||
| ASCE 25 | 38.1 | 69.85 | 69.85 | 7.54 | 12.4 | 700 | 6-12 |
| ASCE 30 | 42.86 | 79.38 | 79.38 | 8.33 | 14.88 | 700 | 6-12 |
30-lb ASCE Rail workshop
