Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of railway spike in China, also supports customized service with low price. Please feel free to buy cheap railway spike made in China here from our factory.
Size: all types
Standard: GB, DIN, ISO, ANSI/ASTM, B7, BS, JIS etc
Surface: plain or as customer requirement
Packing: bulk in carton, then on pallet, or according to customers
Dog Spike and Screw Spike
Dog spikes and screw spikes are two most common railroad spikes that AGICO manufactures,it is small part used to ensure the safety of railway fastening systems. Both spike functions by the equipped offset head, so as to work as a nail that secure and fasten rails on the rail sleeper.
Screw Spike Types
Screw spike is also called sleeper screw, rail screw, through specific requirements such as length, diameter, drive head and thread profiles, the railway screw spikes can be classified into four types, including the Ss series sleeper screw, the square-head screw spike, the hexagon screw spike, and the double-head screw spike.
Ss series Rail Sleeper Screw Spike
|
Type |
Specification |
Weight/kg |
Surface |
Standard |
|
Ss 1/130 |
M22*130 |
0.451 |
Natural Zinc Paint Oil According to your needs. |
UIC AREMA GB or According to your drawings or samples. |
|
Ss 1/150 |
M22*150 |
0.478 |
||
|
Ss 2/180 |
M22*150 |
0.595 |
||
|
Ss 5/150 |
M24*150 |
0.545 |
||
|
Ss 6/150 |
M26*150 |
0.702 |
||
|
Ss 7/180 |
M24*180 |
0.636 |
||
|
Ss 8/140 |
M24*140 |
0.528 |
||
|
Ss 8/150 |
M24*150 |
0.548 |
Square Head Screw Spike
|
Type |
Specification |
Material |
Surface |
Standard |
|
Square head screw spike |
M22*145 |
45# 55Q Q235 or According to your needs. |
Natural Zinc Paint Oil According to your needs. |
UIC AREMA DIN GB or According to your drawings or samples. |
|
M22*155 |
||||
|
M22*165 |
||||
|
M22*185 |
||||
|
M22*195 |
||||
|
Other kinds |
Hexagon Screw Spike
Specially designed for N clip fastening system, it is very popular in Africa railways. It has very strict bending requirement, special raw material is applied by straightening with no crack after bending 30 degrees or so.
Screw Spike for Wooden Sleeper (high tension screw spike)
Size: 15/16×6-1/2
Surface Treatment: Plain (waxed), Black painting
MOQ: 5000PCS
Packing: 38PCS in 50LB plastic keg
|
Technical specifications of Road Spike |
||
|
Standards: AREMA, UIC or others following customer needs |
Model: according to customer needs |
Type: spike |
|
Head type: various kinds |
Neck type: Various kinds |
Function: to fix rails |
|
Applied range: to fasten rails of the railroad bed |
Body type: various kinds |
Length available: 10--1000（mm） |
|
Tolerance: according to customer needs |
Surface finish: plain oil, black, HDG, galvanized, etc. |
Material: Q235, 35#, 45#, 60#, 16Mn, 65 Mn, 40Cr, 20MnTiB, 35CrMo, 42CrMo |
|
Grade: 3.6, 4.6, 4.8, 5.6, 5.8, 6.8, 8.8, 9.8, 10.9, 12.9 |
Spike specifications: According to customer drawings |
Free sample and product customizing available |
The rail dog spike is put into use in many applications from coal and gold mines to sugar plantations, leisure parks, as well as in some heavy rail applications. GNEE rail spike or dog spikes are manufactured in accordance with a series of international standards such as GB, AREMA or ASTM, BS, UIC, material using either carbon or stainless steel. GNEE fabricates dog spikes in varying sizes to suit each customer
This rail spike is manufactured according to ARMEA specifications. Size: 3/4", 1/2", 5/8" Length: 3", 3-1/2", 4-1/2", 5", 5-1/2", 6" Material: Q235 Surface: Plain MOQ: 5000PCS Packing: 200LB kegs and wooden pallets or according to clients' requirement
This is a track spike with high tensile grade of the AREMA specification. The material is the medium carbon steel.
|
Tensile Strength |
Yield Point |
Elongation (in 2" length sample) |
|
70,000 psi Min |
46,000 psi Min |
25% Min |
Material: 45# Surface: Plain MOQ: 5000PCS Packing: 200LB kegs and wooden pallets or according to clients' requirement
|
Specification |
Material |
Surface |
Standard |
|
5/8×6 '' |
A3,Q235, 45#,55#, etc |
According to customer needs. |
According to customer's drawings or samples. |
|
9/16×5-1/2 '' |
|||
|
3/8''×3-1/2 '' |
|||
|
1/2×3-1/2 |
|||
|
Other kinds |
Steel Material Chemical Composition and Mechanical Properties:
|
C |
Mn |
Si |
P |
S |
|
0.17 - 0.25% |
0.9 - 1.35% |
0.35 Max |
0.04% Max |
0.05 Max |
|
Tensile Strength |
Yield Strength |
Elongation |
Reduction of Area |
Hardness |
|
120,000psi(min) |
92,000psi(min) |
14%(min) |
35%(min) |
HRC22-HRC32 |
Dog Spike Used in Wooden Sleeper or Ties
The dog spike is used to fasten T-shaped rail road track to wooden ties, which has an L-shaped head and square shank, and the underside of whose head is sloped to fit the top surface of the rail base. Spikes with various sizes are provided to meet the different requirements of penetrating length of spikes. The common track spikes are the 5/8”*6” and the 9/16”*5-1/2” for smaller rail sections, and they are usually secured in either 200 lb. kegs or 50 lb. kegs.
