SKL clip rail fastening system
The SKL clip rail fastening system is a widely used type of rail fastening system in the railway industry. It's designed to securely attach railway rails to the underlying railroad ties (sleepers) while allowing for some flexibility to accommodate rail expansion and contraction due to temperature changes. The SKL clip system is known for its effectiveness, ease of installation, and ability to provide consistent rail alignment and stability. Here's an overview of the SKL clip rail fastening system: SKL Clips are the main components that secure the rail to the sleeper. They are typically made of spring steel and have a specific shape that holds the rail foot while allowing some movement.Rail Pads are placed between the rail and the sleeper to provide cushioning and reduce noise and vibrations. Insulators are used to electrically isolate the rail from the sleeper, preventing unwanted electrical currents from passing through the track structure. Screw Spikes: Screw spikes are used to fasten the rail fastening system to the sleeper, providing stability and preventing lateral movement.
SKL clip rail fastening system Specification
| SKL tension clip | Ss35 screw spike | Flat washer | Plastic dowel | Guide plate | Rail pad | |
|---|---|---|---|---|---|---|
| Pieces required | 2 | 2 | 2 | 2 | 2 | 1 |
| Material | 60Si2CrA, 60Si2CrA, 38Si7 | Grade 4.6: Q235; Grade 5.6: 35# Grade 8.8: 45# | Q235 | HDPE, Reinforced Nylon 66 (PA66) | Reinforced Nylon 66 (PA66) | EVA, or rubber |
| Size | skl1,skl3,skl12,skl14 | M24×150mm | Uls7 | For different sizes of screw spike | UIC54, UIC60, 50kg rail, 60kg rail, and other sizes as ordered | |
| NOTE | Hardness: 42-47HRC 5 millions cycles without breaking. Standard: DIN17221, GB/T1222 | Standard: ISO898-1, UIC864-1 and NF F500-50 | Standard: EN10025, EN10139 | To insert into concrete sleeper | Customized products available. | |
FAQ
Q1. What is the advantage about your company?
A1. Our company has professional team and professional production line.
Q2. Whyshould I choose your products?
A2. Our products are high quality and low price.
Q3. The logo and the color can be customized?
A3. Yes, we welcome you to sample custom.
Q4. Any other good service your company can provide?
A4. Yes, we can provide good after-sale and fast delivery.
