The Type IV fastening is a boltless elastic clip system that holds 60 kg/m rails on ballasted high-speed track. It presses the rail foot onto a rubber pad through a pre-embedded iron seat, without bolts, and keeps the gauge in place with insulated gauge blocks. This article explains the system composition, working principle, published technical parameters, and typical applications, based on the manufacturer's specification data and the EN 13146 test series.
Send Inquiry
Chat Now
Description

GNEE RAILWAY RAILWAY Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of Type IV Rail Fastening System: Boltless Elastic Clip Fastener for 60 kg/m Rail in China, also supports customized service with low price. Please feel free to buy cheap Type IV Rail Fastening System: Boltless Elastic Clip Fastener for 60 kg/m Rail made in China here from our factory.



What Is the Type IV Rail Fastening System?



The Type IV elastic clip fastening is a boltless system for the Type IIIb shoulderless concrete sleeper in ballasted track. "Boltless" means the elastic clip is pushed into a pre-embedded iron seat cast into the sleeper, so there is no bolt to tighten, loosen, or retorque during service. The clip presses the rail foot down against a rubber pad, while insulated gauge blocks between the seat shoulder and the rail set the gauge and isolate the rail electrically.



The system is laid with 60 kg/m rails on high-speed railways, including lines rated for 350 km/h operation with mobile units up to 170 kN maximum axle weight, and 250 km/h lines that can also accept a limited number of ordinary passenger vehicles and freight wagons with locomotive axle weights up to 230 kN.



System Composition



Each set of the Type IV fastening consists of elastic clips, rail shoulders (part of the embedded iron seat assembly), insulated gauge blocks, and a rubber rail pad.



 Type IV fastening system

Rail Fasteners
Rail Clip
Rail insulator
rail clip
product-227-280
product-151-149
product-184-137
Type G4/JA/JB spring Clip Rail Shoulder TZ4 G4/G4J Rail insulator RPQ Rail pad
Qty(pcs) 2 2 2 1
Material 60Si2MNA QT450-10 PA66 Naturail or synthetic rubber
Mass or volume 1.60kg/1.26kg/1.28kg 2.80kg 107.3m³/91.4m³ 250m³
Remark used in general areas/rail joints   used in general areas used at rail joints
rail clip

Rail spring clip



The elastic clips are classified into three types: C4, JA, and JB.



  • C4-type clips (20 mm in diameter) are installed in standard sections



  • JA and JB-type clips (18 mm in diameter) are used at rail joints.

JA-type clips (gray anti-rust coating) pair with joint insulated gauge blocks No.7, 8, & 9.
JB-type clips (black anti-rust coating) pair with blocks No.10, 11, 12, & 13.



This ensures proper matching of clip types, coatings, and gauge blocks for optimal performance.

rail insulator

Rail insulator



Insulated gauge blocks are divided into two types:



  • G4 gauge blocks for standard sections
  • G4J gauge blocks for rail joints



Each type has seven specifications: No.7, 8, 9, 10, 11, 12, and 13. For standard gauge, No.9 and No.11 blocks are used.


Except for joint gauge blocks No.7, 8, and 9 (non-black), all other gauge blocks are black.



How the System Works?



  • Boltless clamping. Iron seats are pre-embedded in the concrete sleeper when it is cast. The elastic clip is inserted into the seat and presses down on the rail foot; no bolt is used, so the system holds its clamping force without periodic retightening.



  • Gauge adjustment and insulation. An insulated gauge block sits between the seat shoulder and the rail. Replacing the block with a different number (No. 7 to No. 13) shifts the rail left or right, which adjusts the gauge. Because the blocks are PA66 plastic, they also isolate the rail from the sleeper-side components, keeping track-circuit insulation resistance within requirement.



  • Elastic support and damping. The rubber pad under the rail foot provides vertical elasticity and damping; the manufacturer states the dynamic-to-static stiffness ratio of the assembly is no more than 2.0, which helps control wheel-rail dynamic forces at high speed.



  • Low maintenance. The system uses few parts in a compact arrangement and suits lines maintained with large-scale mechanized operations. Even after the 300 h salt-spray test of EN 13146-6, the fasteners can be disassembled with manual tools.



Technical Parameters



Parameter Value Basis / status
Longitudinal rail resistance (C4 clips) > 9 kN per fastening set Manufacturer specification data
Static stiffness of rubber pad 60 kN/mm (±10 kN/mm) Manufacturer specification data
Static stiffness of fastening assembly 75 kN/mm (−5 / +35 kN/mm) Manufacturer specification data
Dynamic-to-static stiffness ratio ≤ 2.0 Manufacturer specification data
Fatigue performance 3,000,000 cycles, no component damage; gauge widening < 6 mm EN 13146-4 test
Insulation resistance between rails > 3 Ω·km EN 13146-5 test
Pull-out force of embedded iron seat ≥ 60 kN; no visible cracks around the seat Manufacturer specification data
Severe-environment performance 300 h salt spray; fasteners removable with manual tools EN 13146-6 test



Applications



application of Type IV Rail Fastening System



  • Ballasted high-speed lines: 60 kg/m rails on Type IIIb shoulderless prestressed concrete sleepers.



  • 350 km/h lines: laid with mobile units up to 170 kN maximum axle weight.



  • 250 km/h lines: accept a limited number of ordinary passenger vehicles and freight wagons with maximum axle weights up to 230 kN.



  • Mechanized maintenance: the compact boltless structure reduces parts handling and suits lines maintained with large-scale mechanical operations.



  • Retrofit on existing sleepers: the Type IV clip structure can be installed on original Type IIIb shoulderless prestressed concrete sleepers where the embedded seats are available or can be fitted.



Quality and Supply Notes



GNEE RAILWAY RAILWAY supplies rail fastening systems with components manufactured to the specified technical requirements. Typical assemblies include 60Si2MnA spring steel clips, QT450-10 ductile iron shoulders, and PA66 gauge blocks, with material and component specifications confirmed according to the project requirements.



Quality control is managed under ISO 9001 quality management system. Mill Test Certificates (MTC) and relevant inspection or test documents can be provided with the shipment when required.



FAQ


Q1. Which rails and sleepers is the Type IV system designed for?


A. It is designed for 60 kg/m rails on Type IIIb shoulderless prestressed concrete sleepers in ballasted track.



Q2. What does "boltless" mean in practice?


A. The elastic clip is inserted into a pre-embedded iron seat and presses the rail directly; there is no bolt to tighten or retighten, which reduces maintenance work.



Q3. How is gauge adjusted?


A. By replacing the insulated gauge blocks. Seven numbers (No. 7 to No. 13) are available; standard gauge typically uses No. 9 and No. 11. The lateral shift per block number should be taken from the approved drawings.



Q4. Does the system provide electrical insulation?


A. Yes. The PA66 gauge blocks isolate the rail from the embedded seat, and the assembly is tested to EN 13146-5 with insulation resistance above 3 Ω·km between rails.



Q5. Can the system be used on existing sleepers?


A. Per the manufacturer, the Type IV clip structure can be installed on original Type IIIb shoulderless prestressed concrete sleepers. Verify sleeper condition and embedded-seat availability on site first.



Q6. Which standards apply to the system?


A. Assembly tests follow EN 13146-4/-5/-6; clip material follows GB/T 1222 (60Si2MnA); general requirements for high-speed railway fastenings follow the TB/T 3395 series, with the exact Type IV designation confirmed against approved drawings.
