E2056 Clip For Railway Fastening System

Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of e2056 clip for railway fastening system in China, also supports customized service with low price. Please feel free to buy cheap e2056 clip for railway fastening system made in China here from our factory.

The E-type railway fastener system is an intelligent adapter developed for the dynamic load characteristics of railway tracks. It realizes the dynamic coupling of rails and sleepers through the cooperative deformation mechanism between components. The core E-type spring clip (such as E1817, E2056) of the E clip fasteners system adopts 60Si2MnA spring steel. It absorbs the impact force through elastic deformation when the train passes, and cooperates with the rigid limit of the rail shoulder to control the lateral displacement of the rail within ±0.5mm.

The rail shoulder is made of QT500-7 ductile iron to provide lateral restraint; the HDPE rail pad is responsible for shock absorption and buffering; the reinforced nylon 66 rail insulation isolates the current and ensures the safety of the track circuit.

E2056 railway fastener system spring clip is a type of E-type spring clip, which plays an important role in the E-type railway track system.

Scope of application: Suitable for straight lines or curves with a radius of ≥350m, and tracks with 60 rails and type III non-shoulder concrete sleepers.

Function: The main function is to fasten the rails to the sleepers to prevent the rails from undesired movement, bending, warping, etc., to ensure the integrity and stability of the track, and at the same time absorb the impact energy generated by the train running and play a shock-absorbing role.

As a professional fastening system supplier in the field of rail transportation, GNEE RAIL is committed to providing safe and reliable connection solutions for global railway construction. Our product range covers various key components such as rail fasteners, anti-loosening devices, insulation components, etc., which are suitable for diverse needs from ordinary railways to high-speed passenger dedicated lines. Through a strict quality control system, we ensure that each product has excellent fatigue resistance and long-term stability. With rich project experience, we can provide targeted technical solutions for regions with different climatic conditions and geological characteristics, helping customers to build a safe and efficient railway transportation network.

Hot Tags: e2056 clip for railway fastening system, China e2056 clip for railway fastening system manufacturers, suppliers, factory, 9 Types Of Rail Fastenings System, E clip Fastening System, J8 Heyback Spring Clip, J9 Heyback Spring Clip
