Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of dtiii iv | dtvi 1 2 fasteners system in China, also supports customized service with low price. Please feel free to buy cheap dtiii iv | dtvi 1 2 fasteners system made in China here from our factory.
As a top railway fastening system manufacturer in China, GNEE RAIL Rail has 15 years' experience in providing various types of rail fastening system, such as high speed rail fastening system, common rail fastening system and subway fastening system.
GNEE RAIL has a full casting production line, it adopts flaskless molding vertical line. With advantages of high precision, high efficient, environmental protection and low pollution, the daily output of casting production line can reach 100 tons.
Common rail fastening system
DT Ⅲ & DT Ⅳ fastening system:
Structural Features:
- A shoulderless fastening system utilizing Type B clips from standard railway Type I elastic fasteners. The assembly comprises:
- Upper steel baseplate
- Foamed aluminum plate
- Lower steel baseplate
- Leveling shim
- A composite rail pad (carbon fiber-reinforced polymer layer + rubber damping layer) is installed between the rail and upper baseplate.
Performance Characteristics:
- Low vertical static stiffness (~21 kN/mm)
- Excellent elasticity for effective vibration absorption
- Optimized for impact energy dissipation
Application:
Designed for heavy-haul, high-frequency operating conditions.
DTVI1 Fastening System:
Structural Features:
- Utilizes arched elastic clips for rail retention
- Replaces conventional rail seats with gauge-adjustment blocks
- Transmits lateral forces to sleeper shoulders
Performance Characteristics:
- Enables track gauge adjustment
- Maintains track geometry stability
- Restricts longitudinal/lateral rail movement
Application:
Primarily deployed in switch and crossing areas (S&C zones).
DTVI2 Fastening System:
Structural Features:
Elastically detached fastening system consisting of:
Steel baseplate
Elastic clips
Plate I & II
Gauge shims
Spike bolts
Short sleepers
Heavy-duty spring washers
Nylon sleeves
Leveling shims (for vertical adjustment)
Performance Characteristics:
- Large gauge adjustment capacity (±16mm)
- Enhanced elasticity for monolithic trackbeds
- Bolt-free clip design reduces maintenance
- Accommodates post-construction adjustments
Application:
- Main applications:
- Underground line monolithic trackbed switches
- Elevated track formations
- Short-sleeper trackbeds in tunnels
About Us
With strict international quality certification and advanced production technology, GNEE RAIL ensures that each product has excellent durability, fatigue resistance and environmental adaptability, ensuring the long-term safe and stable operation of the track structure. At the same time, we provide customized design and technical support to help customers cope with the challenges of different climatic conditions, geological environments and technical standards.
